Savio Acta Nox 24A LPG open-chamber gas boiler

Technical Features

Model: Basica DGT 24A;
Type: Open chamber with natural draft;
Power supply: LPG gas or Propane gas (G30/31);
Series: M290B.24BM;

Energy Characteristics:
Heating energy class: C;
Energy class in sanitary facilities: B;
Sample profile: XL;

Heating/Sanitary performance:
Thermal input (min./nom): 11/26.6 kW;
Useful power (min./max): 9.7/24.1 kW;
Maximum flow rate (ΔT=25 K) / (ΔT=35 K): 13.8 / 9.9 l/min;
Specific sanitary flow rate (ΔT=30 K): 11.5 l/min;

Returns: Returns name 60°/80°C: 90.6%;
Return min. 60°/80°C: 88.1%;
Efficiency at 30% load: 89.6%;

Data:
NOx class: n.3;
Weighted NOx: 135 mg/kWh;
Min./max. temperature (heating): 38 / 85 °C;
Min./max. pressure (heating): 0.3 / 3.0 bar;
Min./max. temperature (sanitary): 35 / 60 °C;
Min. / max. pressure (sanitary): 0.3 / 10.0 bar;
Voltage / Power at nominal heat output: 230~/56 V~/ W;
Protection class: IPX4D;

Dimensions:

(HxWxD): 703x400x325 mm; Weight: 28.7 Kg;
